Product Details:
Payment & Shipping Terms:
|
| Material: | New Carbon Fiber Composite Material | Theory: | Centrifugal Pump |
|---|---|---|---|
| Max Flow: | 400 M3/h | Max Head: | 50m |
| Type: | Horizontal | Structure: | Single-stage Pump |
| Product Name: | Carbon Fiber Chemical Pump | Warranty: | 12 Months |
| Brand Name: | Chengdu Yongyi/OEM | ||
| Highlight: | corrosion resistant pumps,chemical resistant pump |
||
Carbon Fiber Composite Material Chemical Transfer Pumps For Calcium Chloride Pump
Mainly Used:
Brief Introduction of DCS Material
304, 316, 316L, 904L, FCr30, CD4MCu, DTCr30, F33, 2507, A33, Hastelloy, K alloy, 20# alloy, LEWMET85# alloy, etc. are the common corrosion resistance material, but it is unavoidable to be corrosed in contact with chemical liquid.So, non-mental material is becoming more and more popular in corrosion resistance and wear resistance material field and pump manufacture field.
Carbon fiber composite material is our self-developed high-strength composite material. This material is made of carbon fiber, silicon carbide, and chemically reacted with high-performance coupling agent at high temperature.
Features
Acid resistance: hydrofluoric acid, fluosilicic acid, hydrochloric acid phosphoric acid, nitric acid, dilute sulphuric acid, organic acid
Application temperature: application temperature ranges from o to 130C, and differs from mediums
Corrosion resistance: particle size ＜ 20 mesh, solid content ≤ 50%
Service life: its service life is three times as long as that of ordinary metal pump and non-mental pump
Material for Flow Part
Technical Parameter
|
Model |
Flow (m³/h) |
Head |
Rotating speed |
Highest efficiency |
NPSHr (m) |
|
50DCS-250 |
30-50 |
15-28 |
1450 |
40 |
1.4 |
|
50DCS-310 |
30-60 |
25-38 |
1450 |
45 |
1.5 |
|
50DCS-350 |
30-60 |
35-50 |
1450 |
43 |
1.8 |
|
65DCS-250 |
50-80 |
15-28 |
1450 |
48 |
1.8 |
|
65DCS-310 |
50-100 |
25-38 |
1450 |
50 |
2.2 |
|
65DCS-350 |
50-100 |
35-50 |
1450 |
55 |
2.2 |
|
80DCS-250 |
70-140 |
15-25 |
1450 |
61 |
2.5 |
|
80DCS-310 |
70-140 |
25-38 |
1450 |
62 |
2.5 |
|
80DCS-350 |
70-160 |
35-50 |
1450 |
63 |
2.8 |
|
100DCS-310 |
100-220 |
20-35 |
1450 |
57 |
2.8 |
|
100DCS-350 |
100-220 |
35-48 |
1450 |
60 |
2.8 |
|
125DCS-310 |
120-250 |
18-33 |
1450 |
62 |
3 |
|
125DCS-350 |
120-290 |
35-48 |
1450 |
62 |
3 |
|
150DCS-310 |
200-400 |
18-33 |
1450 |
64 |
3.5 |
|
150DCS-350 |
200-500 |
25-45 |
1450 |
65 |
3.5 |
Our Service
Pre-sale service:
1. Prompt in response
2. Price competitiveness as compare with other supplier
3. Factory visit is available if you need.
After service :
1. Routine tracing will be done timely.
2. Provide Clients one-yar warranty to make sure the machine work well.
3. Suggestions and any comments & reflection from customer would be treated in priority.
