Chemical Powder Industrial Agitator Mixer Custom Design Strong Circulation Ability

China Chemical Powder Industrial Agitator Mixer Custom Design Strong Circulation Ability supplier
Chemical Powder Industrial Agitator Mixer Custom Design Strong Circulation Ability supplier Chemical Powder Industrial Agitator Mixer Custom Design Strong Circulation Ability supplier

Large Image :  Chemical Powder Industrial Agitator Mixer Custom Design Strong Circulation Ability

Product Details:

Place of Origin: Sichaun, China
Brand Name: Chengdu Yongyi
Certification: ISO9001
Model Number: Energy-saving Agitator

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD 100-2000/set
Packaging Details: free fumigation export wooden box packaging
Delivery Time: 25 working days after receiveing advance payment
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
Supply Ability: 300 Sets/Month
Contact Now
Detailed Product Description
Type: Multi Type Material: Stainless Steel
Max Capacity: 94m3 Brand: Chengdu Yongyi
Operating: Continuous Operating Length Of Shaft: Customized
OEM: Welcome
High Light:

chemical agitator

,

stainless steel agitator

Customized Design Chemical Powder Industrial Horizontal Agitator Mixer



Product Description


Our company can supply agitators of almost 20 classes and 50 types in total, from the most common types (standard agitators which are in accordance with HB5, SB90, HG/T3796.1~12-2005 standard) to customized types (non-standard agitators which meet production process requirements from customers).


Technical Parameter



1. Open Turbine Agitator with Three Oblique Blades



This kind of agitator is axial-flow agitator and has good convective circulation capability, eddy circulation capability and it can diffuse turbulence. It is applicable for mixing, dispersing, crystallizing particles, reacting, dissolving, solid-liquid suspension and transferring heat.
Application conditions: Dj / D = 0.2-0.8; Applicable viscosity is commonly less than 50000cp; n = 10-400rpm; linear velocity is 2-8 (m / s)

Chemical Powder Industrial Agitator Mixer Custom Design Strong Circulation Ability



Dimension



Dj d d2 h d1 d3 L b t δ Wide Type Narrow Type
B M G B M G
200 30 45 40 M8     8 33.3 3 40 19 0.5 25 12 0.5
250 30 45 40 M8     8 33.3 4 50 42 0.8 31 26 0.6
300 30 45 40 M8     8 33.3 6 60 115 1.4 38 73 1
350 40 60 60 M10     12 43.3 6 70 134 2.2 44 84 1.7
400 40 60 60 M10     12 43.3 8 80 272 3.3 50 170 2.4
450 50 80 80 M10     14 53.8 8 90 305 5.1 56 190 3.9
500 50 80 80 M10 M10 230 14 53.8 8 100 271 6.4 63 146 4.9
550 60 60 90 M10 M10 240 18 64.4 10 110 477 9 69 260 6.8
600 65 100 90 M12 M10 250 18 69.4 10 120 530 10.8 75 292 8.2
650 65 100 90 M12 M10 250 18 69.4 10 130 583 12.2 81 323 9
700 65 100 90 M12 M10 250 18 69.4 10 140 636 13.7 88 361 10
750 65 100 90 M12 M10 250 18 69.4 10 150 689 15.3 94 392 11
800 70 100 110 M16 M10 250 20 74.9 12 160 1069 20 100 611 14.1
850 70 100 110 M16 M10 250 20 74.9 12 170 1145 22.2 106 657 15.4
900 80 120 120 M16 M10 270 22 85.4 12 180 1222 26.5 113 710 19.1
950 80 120 120 M16 M10 270 22 85.4 12 190 1298 29 119 756 20.6
1000 80 120 120 M16 M12 320 22 85.4 12 200 1344 31.6 125 771 22.2
1100 90 135 150 M20 M12 320 25 95.4 14 220 2037 45.4 138 1185 32.3
1200 100 150 150 M20 M12 320 28 106.4 14 240 2245 54.2 150 1310 38.5
1300 110 160 170 M20 M12 350 28 116.4 14 260 2453 64.2 163 1445 45.8
1400 110 160 170 M20 M12 360 28 116.4 14 280 2661 72.6 175 1569 51
1500 120 180 170 M20 M12 360 32 127.4 14 300 2868 85.4 188 1704 60.9
1600 120 180 170 M20 M16 380 32 127.4 16 320 3909 106 200 2280 73.6
1700 130 190 170 M20 M16 420 32 137.4 16 340 4181 118 213 2457 82
1800 130 190 170 M20 M16 430 32 137.4 16 360 4452 131 225 2620 89.7
1900 140 200 190 M20 M16 430 36 148.4 16 380 4724 148 238 2796 105
2000 150 210 190 M20 M16 440 36 158.4 16 400 4995 162 250 2959 111
2200 160 220 220 M20 M16 450 40 169.4 18 440 7009 218 275 4175 148
2400 160 220 220 M20 M16 460 40 169.4 18 480 7697 255 300 4604 172
2600 180 260 260 M20 M16 480 45 190.4 18 520 8384 317 325 5034 220



2. Three-blade Propeller Agitator



Three-blade propeller agitator, similar to three-blade propeller agitator, is axial flow agitator. It has strong circulation ability, low power consumption, and shear ability. Because of these advantages, three-blade propeller agitator is widely used, especially for mixing, diluting, crystallizing, reacting, dissolving, suspending low-viscosity medium, and transferring heat. According to different requirements, stabilizer can be designed as cylindrical stabilizer or stabilizer fin.
Application conditions: Dj / D = 0.2-0.6; Applicable viscosity is commonly less than 10000cp; linear velocity is 2-15 (m / s); wide-type B / Dj = 0.4, narrow-type B / Dj = 0.2.

Chemical Powder Industrial Agitator Mixer Custom Design Strong Circulation Ability

Dimension



Dj d d2 h B d1 d3 b t δ M G
ZHX ZCX
200 25 40 40 32 M8   8 28.3 3 13 1.0
250 30 50 40 40 M8   8 33.3 4 30 1.1
300 30 50 40 49 M8   8 33.3 4 36 1.3
350 35 55 60 57 M8   10 38.3 6 92 2.6
400 40 65 60 65 M10   12 43.3 6 106 2.8
450 40 65 60 73 M10   12 43.3 6 119 3.3
500 45 70 80 82 M10 M10 14 48.3 8 236   7.2
550 50 80 80 90 M10 M10 14 53.8 8 260   7.5
600 55 85 80 98 M12 M10 16 59.3 8 282   8
650 65 85 90 105 M12 M10 18 95.4 8 302   9.5
700 65 100 90 114 M12 M10 18 69.4 10 513   12.5
750 70 110 110 122 M16 M10 20 74.9 10 549   16
800 70 110 110 130 M16 M10 20 74.9 10 587   20
850 80 120 120 138 M16 M10 22 85.4 10 621   25
900 80 120 120 145 M16 M12 22 85.4 10 657   28
950 80 120 120 155 M16 M12 22 85.4 12 1005   35
1000 80 120 120 163 M16 M12 22 85.4 12 1057   40
1100 90 145 150 179 M16 M12 25 95.4 12 1160   50
1200 100 145 150 196 M20 M16 28 106.4 12 1330   52
1300 100 145 150 212 M20 M16 28 106.4 12 1373   62
1400 110 180 150 228 M20 M16 28 116.4 12 1478   65
1500 120 180 180 244 M20 M16 32 127.4 16 2812   100
1600 125 180 180 260 M24 M20 32 132.4 16 2995   110
1700 130 180 200 276 M24 M20 32 137.4 16 3179   135
1800 130 180 200 293 M24 M20 32 137.4 16 3381   138
1900 140 220 220 310 M24 M20 36 148.4 16 3571   158
2000 140 220 220 325 M24 M20 36 158.4 16 3560   170
2200 150 220 240 358 M24 M20 36 169.4 18 5220   238
2400 160 220 240 390 M24 M20 40 190.4 18 5686   260
2600 180 250 280 420 M24 M20 45 190.4 18 6124   298
2800 180 250 280 455 M24 M20 45 190.4 20 8190   372
3000 180 250 280 490 M24 M24 45 190.4 20 8820   428
3200 180 250 300 520 M24 M24 45 190.4 22 11325   545
3400 180 250 300 555 M24 M24 45 190.4 22 12089   628
3600 180 250 300 585 M24 M30 45 190.4 24 15163   702
3800 200 270 300 620 M24 M30 45 210.4 24 16070   832
4000 200 270 300 650 M24 M30 45 210.4 24 16848   856



Why Choose Us

  1. Yongyi’s Vision: Try our best to contribute to pump industry and the world
  2. Quality Awareness: We persevere in high quality and keeping improving
  3. Service Concept: We do not only provide products of high quality, but also high quality service
  4. Core Value: Maximize the value of products

Chemical Powder Industrial Agitator Mixer Custom Design Strong Circulation Ability



FAQ

Chemical Powder Industrial Agitator Mixer Custom Design Strong Circulation Ability
1. Q: Are you a manufacturer or trading company?
A: We are a manufacturer established in 1995, professional manufacturer of chemical-process pump and energy-saving mixer with more than 20-year experience.
2. Q: What's your delivery time?
A: The batch order will be shipped within 40 working days after receiving deposit.
3. Q: What's your warranty service policy?
A: 12 Months for all products, and some products warranty is 24months.
4. Q: What information I need to offer for quotation?
A: Medium: ____________ PH: ________
Specific Gravity: _______ Temperature: _________
Capacity/Flow: ________m3/h Head: _________m
Voltage: ____________V Frequency: _________Hz
Power:_____________KW
5. Q: What is your minimum quantity?
A: One set is also welcomed to us.
